Order Picker
Designed for Efficiency
- Models
- MO20-30X
- Capacity
- 2000-3000kg
The all-new Yale® Order Picker Pallet Truck is built to be tough, intelligent, dependable and efficient. Designed for horizontal transportation efficiency in medium to high-intensity applications, it excels in confined spaces. Using the extended forks option up to two pallets or three Euro pallets crosswise can be easily transported.
- Increased productivity
- Reliable performance
- Easy to maintain
Dual function to ease warehouse operations
The Yale MOX Series has been designed with flexibility in mind. It is suitable for both low level order picking as well as loading and unloading lorries.
Increased productivity
Reliable performance
Easy to maintain
Improved Productivity
Excellent ergonomics
- Increased productivity enhancing speeds in both laden and unladen condition.
- Range of battery sizes to suit different application levels.
- Quick change lateral battery extraction for lower downtime.
- Wide range of driving wheels available for different applications.
- Wide range of fork combinations to suit different applications.
- SmartLiftTM option combines travel and lifting for faster load handling.
- Robust chassis design in line with the Class III range improves protection.
- Higher ground clearance of pull rods helps to avoid damage when travelling on ramps.
- Bushing design improves wear and tear resistance.
- Suspended MDU shock absorption reduces stress on the frame and electronic components.
- Dual processors controller for increased reliability.
- Battery cover protects from falling objects.
- Smooth motor cover for ease of cleanliness and reduced dirt retention.
- Service intervals of 1000 operating hours.
- Easy to replace most exposed parts.
- The truck is provided with a diagnostic port to allow direct access to the connector.
Powerful traction motor increases performance and productivity.
- The suspended Motor Drive Unit provides improved comfort for the operator.
- Progressive speed reduction comes as standard.
- Caster wheels are fully suspended and connected by a torsion bar to provide improvement in rolling behaviour when cornering.
| Model | Load Capacity | Lift Height | Turning Radius | AST (wide / long) | Battery Capacity | Overall Width | Weight |
|---|---|---|---|---|---|---|---|
| MO20X | 2000kg | 120mm | 2374mm | 2985mm | 24V / 375Ah(V/Ah) | 750mm | 807kg |
| MO25X | 2500kg | 120mm | 2374mm | 2985mm | 24V / 375Ah(V/Ah) | 750mm | 824kg |
| MO30X | 3000kg | 120mm | 2374mm | 2985mm | 24V / 375Ah(V/Ah) | 750mm | 824kg |
Yale Vision telemetry
Complete fleet visibility and control
Yale Vision provides real-time fleet monitoring for more informed decisions. The solution offers easy-to-use dashboards and analytics to manage cost, optimise productivity and protect assets.
Yale Power Suite
Unlock the True Power of Your Operation
Yale Power Suite has the industry’s widest range of power sources from a variety of brands, so you get the best solution available to maximize your operations. Our team has deep industry knowledge about forklift power sources to evaluate your application and recommend the power source that gives you the best return on your investment.
