MOVING MAST REACH TRUCK WITH TILTING FORKS
Productivity and comfort
- Models
- MR14-25
- Capacity
- 1400-2500kg
The next level in reach truck productivity, delivered through innovation, technology and ergonomic design
- Heavy duty, high capacity mast
- Energy efficient
- Rapid transport of loads
- Precise fork positioning
- Long service intervals
A robust and reliable reach truck range designed to suit a variety of medium to heavy duty applications.
Heavy duty, high capacity mast
Energy efficient
The robust heavy-duty mast design provides high residual capacities and stable load handling enabling faster put away and retrieval times. The 2,000kg heavy duty model can lift a full capacity load to 7.5m and 800kg to 12.75m.
The ECO-eLo energy efficiency mode reduces the maximum engine speed and optimises fuel efficiency and can, dependent on the application reduce energy consumption by up to 20%.
| Model | Load Capacity | Lift Height | AST (wide / long) | Battery Capacity | Weight |
|---|---|---|---|---|---|
| MR14 | 1400kg | 10500mm | 2718 / 2764mm | 48V / 280-620Ah(V/Ah) | 6861kg |
| MR16N | 1600kg | 9000mm | 2762 / 2811mm | 48V / 420-775Ah(V/Ah) | 6859kg |
| MR16 HD | 1600kg | 11400mm | 2834 / 2896mm | 48V / 560-775Ah(V/Ah) | 8902kg |
| MR16 | 1600kg | 10500mm | 2731 / 2767mm | 48V / 420-775Ah(V/Ah) | 6971kg |
| MR20 HD | 2000kg | 12750mm | 2850 / 2904mm | 48V / 700-930Ah(V/Ah) | 9755kg |
| MR20 | 2000kg | 8150mm | 2795 / 2835mm | 48V / 560-775Ah(V/Ah) | 7970kg |
| MR25 | 2500kg | 8150mm | 2890 / 2915mm | 48V / 700-930Ah(V/Ah) | 8902kg |
LITHIUM-ION BATTERIES AND CHARGERS
RUGGED TRUCKS. SMARTER BATTERIES.
Our forklift battery systems are purpose-built for Yale lift trucks. They’re tested to work together — truck, battery and charger — to maximise performance, safety and reliability, and to relieve operations of the compatibility risks and hassles of third-party power and charging solutions.
Yale Vision telemetry
Complete fleet visibility and control
Yale Vision provides real-time fleet monitoring for more informed decisions. The solution offers easy-to-use dashboards and analytics to manage cost, optimise productivity and protect assets. Wireless monitoring, the level one offering of Yale Vision telemetry, is standard equipment on all Series N ICE trucks.
