Counterbalanced Stackers
Versatile pedestrian controlled counterbalanced stacker
- Models
- MC10-15
- Capacity
- 1000-1500kg
Ideal for stacking of goods in low to medium height racking is limited to a few hours per day.
- Ergonomic tiller head
- Multifunction display
- Robust and durable
- Operator platform
- Energy efficiency
The MC series with its high mounted reversible tiller arm can be operated from the rear of the truck or from the large operator platform for ride-on operation. Used for applications where stackers with support arms cannot operate e.g. lifting closed pallets (with bottom boards) directly from the floor
Ergonomic tiller head
Multifunction display
Robust and durable
Operator platform
Energy efficiency
Ipsum ea nisi dolor excepteur qui est enim incididunt labore. Eiusmod officia aute laboris duis elit, sit nulla commodo veniam. Cillum labore esse tempor anim mollit ut in proident, nostrud. Incididunt velit ipsum irure minim elit, culpa eiusmod nisi adipisicing. Amet, fugiat ut velit ipsum dolor ullamco duis incididunt veniam. Consequat, voluptate minim dolor qui nulla sed aute exercitation proident. Elit, cupidatat sint aute do est non exercitation occaecat dolor. Consequat, occaecat ad sunt sint in veniam, in anim ut. Voluptate esse consectetur ut mollit exercitation veniam, dolor do ut. In mollit cillum quis ullamco id velit est dolor esse
The multi functional dash-board display provides information on the status of the truck and alarm conditions should they occur. Operator information includes the battery discharge indicator a d odometer. The red mushroom shaped button can be activated to stop the truck immediately in case of emergency.
The steel welded chassis comes in three lengths and the 939mm maximum width of the truck makes it ideal for handling in tight spaces. A range of masts are available to suit different applications including two stage LFL and three stage FFL configuration as standard.
The large operator platform allows the operator to determine the most comfortable driving position during long shifts and travel distances. The cushioned platform comes with an operator presence switch that prevents the truck from operating without the operator being on-board.
The 4kW AC motor provides instant response to forward and reverse traction. Whilst the maintenance free motor only requires an inspection every 1000 hours and provides low operational costs. The 3kW DC lift motor provides power to match the trucks application. Electronic performance parameters can be matched to the application by a service engineer.
| Model | Load Capacity | Lift Height | AST (wide / long) | Battery Capacity | Weight |
|---|---|---|---|---|---|
| MC10 (pedestrian) | 1000kg | 5076mm | 3111 / 3227mm | 24V / 300Ah(V/Ah) | 2180kg |
| MC10 (robot) | 1000kg | 4176mm | 4225 / 4211mm | 24V / 400Ah(V/Ah) | 2180kg |
| MC12 (pedestrian) | 1200kg | 5076mm | 3258 / 3374mm | 24V / 400Ah(V/Ah) | 2280kg |
| MC12 (robot) | 1200kg | 4176mm | 4362 / 4350mm | 24V / 400Ah(V/Ah) | 2280kg |
| MC15 (robot) | 1500kg | 4176mm | 4503 / 4491mm | 24V / 400Ah(V/Ah) | 2505kg |
| MC15 (pedestrian) | 1500kg | 5076mm | 3406 / 3522mm | 24V / 400Ah(V/Ah) | 2360kg |
